Model
KIA cee’d, 5 doors
Engine
turbocharged 4-cylinder in line, transversally installed
distribution: two overhead camshafts, 16 valves
displacement: 1999 cc
bore x stroke: 86 x 86 mm
max. output: 340hp @ 6400 rpm
max. torque 440nm @ 4720 rpm
lubrication: wet sump
Transmission
front-wheel-drive
gearbox: 3MO Performance or Xtrac 6-speed sequential with paddle shift
clutch: double-disc sintered metal
differential: multi-disc limited slip differential
Chassis
front suspension: McPherson strut, coil springs, gas-filled dampers, anti-roll bar
rear suspension: Multi-link axle, coil springs, gas-filled dampers, anti-roll bar
steering: electrical power assisted rack and pinion
Brakes
dual circuit hydraulic system
front brakes: six-piston calipers, 378 mm steel ventilated discs
rear brakes: two-piston calipers, 280 mm steel discs
Dimensions
Length: 4651 mm
Width: 1950 mm
Wheelbase 2672 mm
BOP
ECU type & Power level: M5
Ballast: -10 kg (endurance -5 kg)
Minimum racing weight: 1255 kg (endurance 1245 kg)
Ground clearance: 70 mm
Price
129,800 €
