Model
Fiat Tipo 365, 4 doors
Engine
Turbocharged 4-cylinder in line, transversally installed
Distribution: one overhead camshafts, 16 valves
Displacement: 1995 cc
Bore x stroke: 84 x 90 mm
Max. output 340hp @ 6000 rpm
Max. torque: 440nm @ 5200 rpm
Lubrication: wet sump
Transmission
Front-wheel-drive
Gearbox: Sadev 6-speed sequential with paddle shift
Clutch: multi-disc
Differential: mechanical limited slip differential
Chassis
Front suspension: McPherson strut, coil springs, gas-filled dampers, anti-roll bar
Rear suspension: McPherson strut, coil springs, gas-filled dampers, anti-roll bar
Steering: electrical power assisted rack and pinion
Brakes
Dual circuit hydraulic system
Front brakes: 6-piston calipers, 380 mm steel ventilated discs
Rear brakes: 2-piston calipers, 290 mm steel discs.
Dimensions
Length: 4532 mm
Width: 1950 mm
Wheelbase: 2636 mm
BOP
ECU & Power level: M5
Ballast: -10 kg (endurance -5 kg)
Minimum racing weight: 1255 kg (endurance 1245 kg)
Ground clearance: 70 mm
Price
Temporary technical form
