Model
Honda Civic FK7 Hatchback, 5 doors
Engine
Turbocharged 4-cylinder in line, transversally installed
Distribution: two overhead camshafts, 16 valves
Displacement: 1998.2 cc
Bore x stroke: 86 x 86 mm
Max. output 340hp @ 6200 rpm
Max. torque: 420nm @ 3800 rpm
Lubrication: wet sump
Transmission
Front-wheel-drive
Gearbox: Sadev or Xtrac 6-speed sequential with paddle shift
Clutch: JAS twin-disc sinter-metallic
Differential: mechanical limited slip differential
Chassis
Front suspension: McPherson strut, coil springs, gas-filled dampers, anti-roll bar
Rear suspension: multi-link axle, coil springs, gas-filled dampers, anti-roll bar
Steering: electrical power assisted rack and pinion
Brakes
Dual circuit hydraulic system
Front brakes: 6-piston calipers, 380 mm steel ventilated discs
Rear brakes: 2-piston calipers, 260 mm steel discs
Dimensions
Length: 4549 mm
Width: 1950 mm
Wheelbase: 2700 mm
BOP
ECU type & Power level: M5 / C5
Ballast: +20 kg (endurance +10 kg)
Minimum racing weight: 1285 kg (endurance 1260 kg)
Ground clearance: 70 mm
Price
135,000 €
